Mini Wah Volume Pedal GK-64

GK-27 REPEATER Looper Specifications & Features
I. Product Specifications
Three Loop Storage: Supports storing 3 independent loops, with a total recording time of up to 11 minutes and up to 5 minutes per loop.

Unlimited Overdubbing: Each loop allows unlimited overdubs.

Undo/Redo Function: Each loop supports unlimited undo and redo of the last audio layer.

3-Speed Playback: After recording, you can choose from 3 playback speeds.

USB File Management: Supports importing/exporting WAV audio files to/from a computer via USB connection.

One-Touch Operation: All functions—including recording, playback, stop, overdub, undo, redo, and delete—are controlled by a single footswitch.

Power Supply: Supports 9V DC adapter (center negative) or Type-C port (recommended 5V 1A; USB port can be used for file transfer).

II. Panel Description
LOOP Knob: Adjusts the playback volume of the loop.

Ready-record Function: Activate by pressing the button. Recording starts automatically once instrument input is detected. Sensitivity is adjustable.

Ready-record Indicator: Blinking blue light indicates that Ready-record is enabled.

Loop Status Indicator: Red means recording, green means playback, green flashing means temporary mute.

LOOP Footswitch: Controls recording, playback, stop, overdub, undo/redo, delete, and other functions.

Recording Storage: Can store three recorded loops.

Speed Control: Supports three playback speed options.

Power Interface: 9V DC adapter input.

Input Jack: 1/4" mono audio input.

Output Jack: 1/4" mono audio output.

TYPE-C Port: Supports power supply and computer file transfer. When connected to a computer, only data transfer is available; other pedal functions are temporarily disabled.
